Product introduction

The HCDP-13 series transmitter uses a micro-melt pressure sensor as the signal measurement element. Both the Hirschmann connector type and the integrated cable type adopt a single-chip solution. It uses a highly integrated dedicated sensor signal conditioning chip, digital circuit design, 1Wire digital communication calibration, no potentiometer, and features high precision and high stability. Hirschmann standard quick-installation interface, optional digital tube or LCD on-site display, realizes the display of various engineering quantities. The integrated cable type has a high level of protection and is suitable for use in complex sites such as outdoor and diving environments. Applying advanced temperature compensation and nonlinear correction technology, the pressure chamber of the micro-melting sensor is made of a single-piece integrated structure of 17-4PH stainless steel. The product is characterized by no O-rings, no welds, no silicone oil or other organic matter, and resistance to strong impact and durability. It is especially suitable for hydraulic and pneumatic use under harsh conditions.

Selection and application

The pressure transmitter is a device that converts the weak signal output by the pressure sensor into a standard signal output

through a specialized conditioning circuit. Optional signal outputs include (4-20)mA@HART, RS485@Modbus protocol, voltage

output, etc.

Features:

1.Easy to set up and can realize continuous detection of pressure signals.

2.The detection accuracy of the pressure transmitter is several times higher than that of the pressure switch, and the reliability of its components is better.

3.The sensitive components used are of non-mechanical structures, which basically require no maintenance and can reduce the damage rate.

Application case

HCDP-10 Hirschmann connector type for process pressure or level measurement.
