LCD HART or RS485 Silicon Piezoresistive Pressure Transmitter 0-60MPa Liquid Level Measurement Pressure Sensor

Pressure transmitter adopts the imported silicon piezoresistive sensor as the pressure measuring element, which is divided into simple type, sanitary type and industrial type.

The simple type pressure transmitter has Hirschman joint type and integrated cable type, both using a single-chip scheme. This chip is a special signal conditioning chip for pressure transmitters with high integration, high precision and good stability. It features 1-wire digital communication calibration with no potentiometer.

The sanitary type pressure transmitter’s planar diaphragm design solves the problem of common pressure transmitters being unable to clean dirt and impurities from pressure leading holes. It adopts advanced temperature compensation and nonlinear correction technologies, so it is particularly suitable for applications in food and pharmaceutical industries that require high-level sanitary conditions.

The industrial pressure transmitter adopts a high-performance 24-bit AD converter, with a backlight LCD, optional HART or RS485 communication, and three buttons on the keyboard for easy adjustment.

Selection and application

Product video

Application case

HCDP-20 Industrial Pressure Transmitter. It is a digital, intelligent pressure transmitter with a die-cast aluminum case. It can be widely used in petroleum, chemical industry, steel, electric power, light industry, environmental protection and other industrial fields.

Technical data
